Custom Hydraulic Manifold Block & Solenoid Valve Base

Custom aluminum hydraulic manifold blocks

Custom Hydraulic Manifold Block & Solenoid Valve Base

Optimize your fluid power systems with our custom hydraulic manifold blocks. Precision CNC-machined for leak-free performance, these integrated valve bases simplify plumbing and reduce pressure drops. Available in high-strength aluminum or steel, fully tailored to your specific schematics and flow requirements.

Material	Aluminum (6061/7075), Carbon Steel, Stainless Steel
Process	5-Axis CNC Machining & Deep Hole Drilling
Max Pressure	Up to 10,000 PSI (Material Dependent)
Port Threads	NPT, SAE, BSPP, Metric (Customizable)
Quality Standard	100% Burr-Free & Pressure Tested
Application	Fluid Power & Solenoid Valve Integration

Product Description

Custom Hydraulic Manifold Block & Solenoid Valve Base

Engineered for flawless fluid control, our custom hydraulic manifolds eliminate complex piping, minimize leak points, and ensure efficient power transmission for demanding industrial and mobile hydraulic applications.

Technical Specifications

Material Options	High-strength Aluminum, Carbon Steel, Stainless Steel, Ductile Iron
Machining Process	Precision CNC Milling, Turning, and Deep Hole Drilling
Thread Standards	NPT, SAE (O-Ring Boss), BSPP, BSPT, Metric
Operating Pressure	Aluminum: Up to 3,000 PSI \| Steel/Iron: Up to 10,000 PSI
Surface Finish	Hard Anodizing, Zinc Plating, Black Oxide, Nickel Plating
Valve Compatibility	D03, D05, D07, Sun/HydraForce Cartridge Valves, Solenoid Valves
Deburring	Advanced thermal/mechanical deburring for 100% clean channels
Marking	CNC or Laser Engraved Port IDs (e.g., P, T, A, B) & Logos

APPLICATIONS

Our aluminum extrusion and CNC machining solutions provide high-performance support for diverse industries:

Industrial Heavy Machinery & Presses Construction & Agricultural Equipment Material Handling & Forklifts Aerospace & Marine Hydraulic Systems Plastic Injection Molding Machines

WHY CHOOSE US

📦 Advanced CNC Capabilities Utilizing state-of-the-art multi-axis CNC machines for precise deep hole drilling and complex intersecting channels.

⚙️ Strict Burr-Free Guarantee Employing rigorous deburring and high-pressure flushing processes to ensure zero contamination in your hydraulic fluid.

📜 Leak-Free Performance Every manifold undergoes 100% strict pressure and leak testing before shipment to guarantee flawless sealing.

🛠️ Material Traceability We source only premium-grade metals with full material certifications to ensure structural integrity under extreme high pressure.

💎 Expert DFM Support Our engineering team provides Design for Manufacturing (DFM) feedback to optimize flow paths, reduce block weight, and lower machining costs.

🕒 Rapid Turnaround From custom prototyping to high-volume mass production, our efficient workflows ensure your supply chain stays on schedule..

Our Advantages

Exquisite Craftsmanship & Premium Selection

Custom Tooling & Design

OEM/ODM tooling and product design based on your drawings.

Profile Extrusion

High-precision aluminum extrusion for stable structural components.

Precision CNC Machining

Multi-axis CNC machining with tight tolerance processing.

Surface Finishing

Anodizing, sandblasting, brushing, and powder coating options.

Service Process Flow

Customization Capability

✓Custom Schematic Conversion: We can convert your hydraulic circuit diagrams into fully optimized 3D manifold solid models.

✓ Bespoke Valve Cavities: From sleek matte textures to high-gloss or custom colored anodizing to perfectly match your brand identity.

✓ Tailored Port Layouts: Custom positioning of inlet (P), return (T), and working ports to perfectly fit your machine's space constraints.

✓ Specific Surface Treatments: Anti-corrosion finishes customized for harsh environments (e.g., salt spray resistance for marine use).

✓ Clear Identification: Custom laser engraving for port labels, flow directions, and your corporate branding.

Frequently Asked Questions

Q1: What material should I choose for my hydraulic manifold?

A: We typically recommend high-strength aluminum (like 6061-T6) for systems operating up to 3,000 PSI due to its excellent machinability and lightweight nature. For heavy-duty applications up to 10,000 PSI, carbon steel or ductile iron is required.

Q2: How do you guarantee the internal channels are free of burrs?

A: Contamination is the enemy of hydraulic systems. We use specialized cross-hole deburring tools, thermal deburring techniques, and thorough high-pressure ultrasonic cleaning to ensure all internal passageways are 100% clean and burr-free.

Q3: Can you machine cavities for specific brands of cartridge valves?

A: Absolutely. We have extensive cavity tooling libraries and can precision-machine ports and cavities to perfectly fit valves from industry leaders like Sun Hydraulics, HydraForce, Parker, and Rexroth.

Q4: Do I need to provide a 3D model, or can you work from a schematic?

A: While providing a 3D CAD model (STEP/IGES) speeds up the process, our experienced engineers can also design the physical manifold layout directly from your 2D hydraulic schematics or circuit diagrams.
